Moving towards high-end digitalization.
LED screens / LED displays
Magnetic front maintenance
For indoor LED screens, LED displays, all LED modules, receiving card,power supply, cables can be take out from the front to fit the wall mounted installation.
Easy structure / Precise alignment
The LED screens, LED displays, cabinets use material of iron or aluminum, size can be custommized. CNC finish on cabinet edges gurantee the perfect alignment between each LED module, LED cabinets
Full range of indoor LED screens, LED displays, LED wall, pixel pitch ranges from 2.5mm to 10mm with different sizes to match different kinds of applicaiton
| Pixel pitch（mm） | 2.5mm | 3mm | 4mm | 5mm | 6mm |
| Pixel Matrix Per SQM | 160000 | 111111 | 62500 | 40000 | 27777 |
| Pixel Configuration | SMD 2020 | SMD 2020 | SMD 2020 | SMD 3528 | SMD 3528 |
| Brightness(nits) | ≥900 | ≥1000 | ≥1000 | ≥1200 | ≥1200 |
| Scan | 1/32 | 1/32 | 1/16 | 1/16 | 1/16 |
| Power Con.(Max/Avg) | 500/200 w /sq.m | 600/250 w /sq.m | 600/250 w /sq.m | 600/250 w /sq.m | 500/200 w /sq.m |
| Modules Dimension(mm) | 6.3’’ x 6.3’’ 160mm x 160mm | 7.56’’ x 7.56’’ 192mm x 192mm | 10.08’’ x 5.04’ 256mm x 128mm | 12.6’’ x 6.3’ 320mm x 160mm | 7.56’’ x 7.56’’ 192mm x 192mm |
| Modules Solution | 64 x 64 | 64 x 64 | 64 x 32 | 64 x 32 | 32 x 32 |
| Cabinets Dimension | 18.89’’ x18.89’ ’’x 3.35’’ 480mm x 480mm x 80mm | 22.6’’ x 22.6’ ’’x 3.35’’ 576mm x 576mm x 85mm 30.23’’ x 30.23 ’’x 3.35’’ 768mm x 768mm x 85mm | 20.16’’ x 20.16’ ’’x 3.35’’ 512mm x 512mm x 85mm | 25.19’’ x 25.19’ ’’x 3.35’’ 640mm x 640mm x 85mm | 37.8’’ x 37.8 ’’x 5.51’’ 960mm x 960mm x 140mm |
| Cabinets Solution | 192 x 192 | 192 x 192 256 x256 | 128 x 128 | 128 x 128 | 160 x 160 |
| Cabinets Weight(kg) | 15kg/ 33.06lbs | 17kg/ 37.47lbs 21kg/ 46.29lbs | 20kg/ 44.09lbs | 20kg/ 44.09lbs | 17kg/ 37.47lbs |
| Serivice Access | Front & Rear | ||||
| Refresh Rate(HZ) | ≥1920 | ||||
| Grey Scale(bit) | 16 | ||||
| Viewing Angle(H/V) | 160°/160° | ||||
| IP Rate | IP31 / IP31 | ||||
| Input Voltage(AC) | 110V / 240V 50/60 HZ | ||||
| Operating Temperature | -20° ~ 60 ° | ||||
| Lifespan(hrs) | >100,000(hrs) |
LED Flexible Screen
Flexible LED screen can be bended
Flexible LED screen module is specially designed with soft PCB and rubber plastic parts which can be bend concave and convex without affecting the the normal working of the LED diode board.
Magnetic front maintenance
With the strong magnets, flexible LED display modules can be easily anywhere to form different creative shapes of LED display such as LED column, curve LED display, concave and convex. The installation and maintenance can be done from the front.
The flexible LED screen / flexible LED display utilizes soft PCB with high flexibility which can be bended to creatve concave and convex curve shapes.
| Pixel pitch（mm） | 2.5mm indoor | 3 mm indoor | 4 mm indoor | 6mm indoor |
| Pixel Matrix Per SQM | 160000 | 111111 | 62500 | 27777 |
| Pixel Configuration | SMD2020 | SMD2020 | SMD2020 | SMD3528 |
| Brightness(nits) | 800 | 900 | 1000 | 1000 |
| Scan | 1/32 | 1/32 | 1/16 | 1/16 |
| Power Con.(Max/Avg) | 200W/sqm(Avg)600W/sqm(Max) | |||
| Modules Dimension | 6.3’’ x 6.3’’ 160mm x 160mm | 7.56’’ x 7.56’’ 192mm x 192mm | 10.08’’ x 5.04’ 256mm x 128mm | 7.56’’ x 7.56’’ 192mm x 192mm |
| Modules Solution | 64×64 | 64×64 | 64×32 | 32×32 |
| Modules Weight | 0.15 kg /0.33 lbs | 0.16 kg /0.35 lbs | 0.14 Kg /0.31 lbs | 0.15 kg /0.33 lbs |
| Serivice Access | Front | |||
| Refresh Rate(HZ) | ≥1920 | |||
| Grey Scale(bit) | 16 | |||
| Viewing Angle(H/V) | 160°/160° | |||
| IP Rate | IP31 / IP31 | |||
| Input Voltage(AC) | 110V / 240V, 50/60 HZ | |||
| Operating Temperature | -20° ~ 60 ° | |||
| Lifespan(hrs) | >100,000(hrs) |
CONTROLLED AND DYNAMIC INDOOR COMMUNICATION
Greater brightness, more possibilities with ever-larger formats, useable in window displays; indoor LED communication will soon be everywhere!
Our Prismatronic Indoor LED screens operate using the best technology the market has to offer: SMD technology with a “Die Cast” structure for modular and lightweight communication.
- Pitch from 2.8 to 4.8 mm.
A super bright version for use in already well-lit areas or window displays.
SUPER LED
- Eye-catching communication thanks to static or animated images.
- Autonomous content management
- Pitch: 2.8 to 4.8 mm
Super bright: 5000 nits in High brightness version - Black LED encapsulation for an enhanced contrast
- Factory colour calibrationthen on-site re-calibration
- SMD Technology: better contrast, greater viewing angle, sharper image
Optional extra
LED display surround to blend in with the surroundings.
